酒店厨房排烟罩采用不锈钢拉丝工艺，不仅外观美观，而且防腐防锈。酒店厨房排烟罩内腔采用大空间设计，使油烟杂质吸收更充分，油烟吸收率应大于95%。那你知道济南酒店厨房排烟罩的生产、安装方法及日常维护事项是怎样的吗？

The smoke exhaust hood of the hotel kitchen adopts excellent stainless steel wire drawing process, which not only has beautiful appearance, but also has corrosion prevention and rust prevention. The interior of the smoke exhaust hood in the hotel kitchen is designed with large space to make the absorption of oil smoke impurities more sufficient, and the absorption rate of oil smoke should be greater than 95%. Do you know the production, installation and daily maintenance of kitchen smoke hoods in Jinan Hotel?

食堂油烟机排烟罩生产要求。

Production requirements for smoke exhaust hood of cooking fume hood in canteen.

1.油网烟罩后密封板、前密封板、前页、上滑槽和下滑槽的所有外露边缘均有扣边；

1. All exposed edges of the rear sealing plate, front sealing plate, front page, upper chute and lower chute of the oil screen smoke hood have buckle edges;

2.油网烟罩后密封板与前密封板分段短焊，其中前密封板HL表面暴露；

2. The rear sealing plate and the front sealing plate of the oil screen hood are short-welded in sections, and the HL surface of the front sealing plate is exposed;

3.油网烟罩前页与油网烟罩前封板连接为分段短焊，焊接面在前封板外露前页HL面向下，二端烟罩连接面分别向上90度；

3. The connection between the front page of the oil screen smoke hood and the front sealing plate of the oil screen smoke hood is short welding in sections. The welding surface is facing downward on the exposed front page HL of the front sealing plate, and the connection surface of the two end smoke hoods is 90 degrees upward;

4.油网烟罩二端的油烟网罩侧密封板和后密封板。前密封板的前页分段短焊，包括同一前页的前端（注：尺寸120mm）。后密封板的油槽位置为全焊和抛光；

4. The side sealing plate and rear sealing plate of the oil smoke screen cover at the two ends of the oil smoke screen cover. The front page of the front sealing plate is short-welded in sections, including the front end of the same front page (note: size 120mm). The oil groove of the rear sealing plate is fully welded and polished;

5.烟罩照明灯须具有防水功能，导线须具有旋转穿线护管。

5. The smoke hood lamp must be waterproof, and the wire must have a rotating threading protection tube.

酒店厨房排烟罩的安装方法。

Installation method of smoke exhaust hood in hotel kitchen.

1.现场安装油烟网罩时，现场拼接的油网烟罩后密封板到油槽处满焊，其余部分为短焊；

1. When installing the oil smoke screen cover on site, the rear sealing plate of the oil smoke screen cover spliced on site shall be fully welded to the oil tank, and the rest shall be short-welded;

2.用M8钢膨胀螺和不锈钢大垫片用于固定油烟网罩和墙壁，膨胀螺钉外露螺纹需螺纹；

2. M8 steel expansion screw and stainless steel large gasket are used to fix the oil smoke screen cover and wall, and the exposed thread of the expansion screw needs to be threaded;

3.油网烟罩前页与地板连接件为螺钉全线或钢丝绳加吊环螺钉，索具螺旋扣；

3. The connection between the front page of the oil screen smoke hood and the floor is the full line of screws or steel wire rope plus eyebolts and rigging turnbuckles;

4.吊装高度:油网烟罩前页下口距地面2000mm，油网烟罩后密封板至油槽底部距地面1900mm；油网烟罩的吊装精度一般为正负10mm。

4. Hoisting height: the lower opening of the front page of the oil screen hood is 2000mm from the ground, and the rear sealing plate of the oil screen hood to the bottom of the oil tank is 1900mm from the ground; The lifting accuracy of oil screen smoke hood is generally plus or minus 10mm.

酒店厨房排烟罩维修方法。

Maintenance method of smoke exhaust hood in hotel kitchen.

1.平时不锈钢橱柜要避免热锅或热水壶直接接触橱柜，这些物品较好放在锅架上。

1. The stainless steel cabinet should avoid the hot pot or hot pot directly contacting the cabinet, and these items should be better placed on the pot rack.

2.平时注意尖锐物品不能触摸台面，避免厨房排烟罩造成橱柜上有划痕或凹痕。

2. Pay attention not to touch the table with sharp objects at ordinary times to avoid scratches or dents on the cabinet caused by the kitchen smoke hood.

3.柜门板根据不同的材料进行不同的清洗方法。

3. The cabinet door plate shall be cleaned according to different materials.

4.避免使用化学物质接触橱柜，对橱柜造成损坏。

4. Avoid using chemicals to contact the cabinet and cause damage to the cabinet.

上述就是为您介绍的有关食堂/饭店油烟机排烟罩的制作要求、安装方法及日常养护方法的内容，对此还有什么不了解的，欢迎前来咨询我们的网站http://www.jntfgd.com，我们会有专门的技术人员为您讲解。

The above is the content about the production requirements, installation methods and daily maintenance methods of the smoke exhaust hood of the kitchen ventilator in the canteen/hotel introduced to you. If you don't know anything about this, please come to our website http://www.jntfgd.com , we will have special technicians to explain to you.
