一、根据风机的进出口径定制同截面的排烟管，方可保证设备的处理效果及设备的经济运行。
1、 According to the inlet and outlet diameter of the fan, the smoke exhaust pipe with the same section can be customized to ensure the treatment effect and economic operation of the equipment.
二、厨房蒸汽散热管路与厨房油烟机排烟管分别安装。
2、 The kitchen steam heat dissipation pipeline and the smoke exhaust pipe of the kitchen range hood shall be installed respectively.
三、厨房排烟管弯头的额曲率半径：
3、 Radius of curvature of elbow of kitchen smoke exhaust pipe:
因为弯头的曲率半径小将增加风管阻力，故一般选择弯头曲率半径为1.5D较为合适，在设置弯头处应预先留下弯头的摆放空间及安装操作空间。
Because the small radius of curvature of the elbow will increase the resistance of the air duct, it is generally appropriate to choose the radius of curvature of the elbow as 1.5D. The placement space and installation operation space of the elbow should be reserved in advance at the place where the elbow is set.
四、安装预留空间：
4、 Space reserved for installation:
油烟净化器的安装位置在电控箱一侧1.5米左右的空间作为油烟净化器维修、维护的空间。
The installation position of the oil fume purifier is about 1.5m on one side of the electric cabinet as the space for the repair and maintenance of the oil fume purifier.
The above is the knowledge brought to you today. Jinan hotel kitchen smoke hood has focused on the industry for many years and continuously provides users with valuable content. Please continue to pay attention to us for more content: http://www.jntfgd.com
