济南酒店厨房排烟罩生产要求：

Jinan Hotel Kitchen Smoke Exhaust Hood Production Requirements:

1.排烟罩后密封板、前密封板、前页、上滑槽和下滑槽的所有外露边缘均有扣边；

1. All exposed edges of the rear sealing plate, front sealing plate, front page, upper chute and lower chute of the smoke exhaust hood have buckle edges;

2.排烟罩后密封板与前密封板分段短焊，其中前密封板HL表面暴露；

2. The rear sealing plate and the front sealing plate of the smoke exhaust hood are short-welded in sections, and the HL surface of the front sealing plate is exposed;

3.排烟罩前页与排烟罩前封板连接为分段短焊，焊接面在前封板外露前页HL面向下，二端烟罩连接面分别向上90度；

3. The connection between the front sheet of the smoke exhaust hood and the front sealing plate of the smoke exhaust hood is short welding in sections. The welding surface is facing downward on the exposed front sheet HL of the front sealing plate, and the connection surface of the two end smoke hoods is 90 degrees upward;

4.排烟罩二端的油烟网罩侧密封板和后密封板。前密封板的前页分段短焊，包括同一前页的前端（注：尺寸120mm）。后密封板的油槽位置为全焊和抛光；

4. The side sealing plate and rear sealing plate of the oil smoke screen cover at the two ends of the smoke exhaust hood. The front page of the front sealing plate is short-welded in sections, including the front end of the same front page (note: size 120mm). The oil groove of the rear sealing plate is fully welded and polished;

5.烟罩照明灯必须具有防水功能，导线必须具有旋转穿线护管。

5. The smoke hood lamp must be waterproof, and the wire must have a rotating threading protection tube.

排烟罩的安装方法:

Installation method of smoke exhaust hood:

1.现场安装油烟网罩时，现场拼接的排烟罩后密封板到油槽处满焊，其余部分为短焊；

1. When installing the smoke screen cover on site, the rear sealing plate of the smoke exhaust cover spliced on site shall be fully welded to the oil tank, and the rest shall be short-welded;

2.用M8钢膨胀螺和不锈钢大垫片用于固定油烟网罩和墙壁，膨胀螺钉外露螺纹需螺纹；

2. M8 steel expansion screw and stainless steel large gasket are used to fix the oil smoke screen cover and wall, and the exposed thread of the expansion screw needs to be threaded;

3.排烟罩前页与地板连接件为螺钉全线或钢丝绳加吊环螺钉，索具螺旋扣；

3. The connection between the front page of the smoke exhaust hood and the floor is the full line of screws or steel wire rope plus eyebolts and rigging turnbuckles;

4.吊装高度:排烟罩前页下口距地面2000mm，排烟罩后密封板至油槽底部距地面1900mm；排烟罩的吊装精度一般为正负10mm。

4. Hoisting height: the lower opening of the front page of the smoke exhaust hood is 2000mm from the ground, and the rear sealing plate of the smoke exhaust hood to the bottom of the oil tank is 1900mm from the ground; The lifting accuracy of smoke exhaust hood is generally plus or minus 10mm.

排烟罩的养护方法：

Maintenance method of smoke exhaust hood:

1.平时不锈钢橱柜要避免热锅或热水壶直接接触橱柜，这些物品较好放在锅架上。

1. The stainless steel cabinet should avoid the hot pot or hot pot directly contacting the cabinet, and these items should be better placed on the pot rack.

2.平时注意尖锐物品不能触摸台面，避免厨房排烟罩造成橱柜上有划痕或凹痕。

2. Pay attention not to touch the table with sharp objects at ordinary times to avoid scratches or dents on the cabinet caused by the kitchen smoke hood.

3.柜门板根据不同的材料进行不同的清洗方法。

3. The cabinet door plate shall be cleaned according to different materials.

4.避免使用化学物质接触橱柜，对橱柜造成损坏。

4. Avoid using chemicals to contact the cabinet and cause damage to the cabinet.

上述就是为您介绍的有关酒店厨房排烟罩的制作要求、安装方法及日常养护方法的内容，对此还有什么不了解的，欢迎前来咨询我们的网站http://www.jntfgd.com咨询！

The above is about the production requirements, installation methods and daily maintenance methods of the hotel kitchen smoke exhaust hood introduced to you. If you have any questions about this, please come to our website http://www.jntfgd.com consulting service
