通风管道是建筑物中用于空气或气体传输的系统，主要应用于内部通风、空调和排烟系统。其基本构成包括管道、弯头、三通等部件，材质涵盖金属（如镀锌钢板、铝板、不锈钢）和非金属（如玻璃钢、聚氯乙烯）。

Ventilation ducts are systems used in buildings for the transmission of air or gas, primarily for internal ventilation, air conditioning, and smoke exhaust systems. Its basic components include pipes, elbows, tees, and other parts, with materials ranging from metal (such as galvanized steel plates, aluminum plates, stainless steel) to non-metal (such as fiberglass, polyvinyl chloride).

通风管道的设计和安装需考虑建筑物结构、使用功能、人员密度和气候环境。设计阶段涉及确定需求、选择材料和布局规划；安装阶段包括准备工作、测量标记、主干管和分支管安装、检查调整以及验收测试，确保管道质量和安全性，避免漏风、震动等问题，最终实现通风管道系统的高效运行。

The design and installation of ventilation ducts need to consider building structure, functional use, personnel density, and climate environment. The design phase involves determining requirements, selecting materials, and layout planning; The installation phase includes preparation work, measurement marking, installation of main and branch pipes, inspection and adjustment, and acceptance testing to ensure the quality and safety of the pipeline, avoid problems such as air leakage and vibration, and ultimately achieve efficient operation of the ventilation duct system.

通风管道按外形分为圆形和矩形，按材质分为普通薄钢板、镀锌薄钢板、不锈钢板等。 通风管道的尺寸设计应根据风量要求和运行压力确定，直径或截面尺寸应满足设计要求。安装规范包括垂直或水平安装、密封连接、牢固支架等。

Ventilation ducts are divided into circular and rectangular shapes according to their appearance, and into ordinary thin steel plates, galvanized thin steel plates, stainless steel plates, etc. according to their materials. The size design of ventilation ducts should be determined based on the air volume requirements and operating pressure, and the diameter or cross-sectional size should meet the design requirements. Installation specifications include vertical or horizontal installation, sealed connections, and secure brackets.

干货来了~给排水、消防、暖通CAD图例符号大全与画法_管道干货来了~给排水、消防、暖通CAD图例符号大全与画法_管道在防火方面，通风管道应采用具有一定防火性能的材料，如镀锌钢板、不锈钢板等金属材料，或者防火性能达到一定标准的玻璃钢、复合材料等。 对于一些防火要求较高的部位或穿越防火分区的通风管道，可以采用防火材料对管道进行包裹，如防火岩棉、防火板等，提高管道的耐火性能。

Dry goods have arrived~Complete list and drawing methods of CAD legend symbols for water supply and drainage, fire protection, and HVAC _ Pipeline dry goods have arrived~Complete list and drawing methods of CAD legend symbols for water supply and drainage, fire protection, and HVAC _ Pipeline In terms of fire prevention, ventilation ducts should use materials with certain fire resistance properties, such as galvanized steel plates, stainless steel plates and other metal materials, or fiberglass, composite materials with certain fire resistance standards. For areas with high fire protection requirements or ventilation ducts that pass through fire compartments, fire-resistant materials such as fire-resistant rock wool, fire-resistant boards, etc. can be used to wrap the ducts to improve their fire resistance performance.

风管包覆防火板 防火隔墙防火板 纤维增强硅酸盐防 …风管包覆防火板 防火隔墙防火板 纤维增强硅酸盐防 …通风管道的安装还需遵循国家和地方规范标准，如《建筑通风与空气调节设计规范》，并制定详细的施工方案。安装过程中需保证管道密封性、稳固性和防火性，避免过长或过曲。

The installation of ventilation ducts also needs to comply with national and local standards, such as the "Code for Design of Building Ventilation and Air Conditioning", and develop detailed construction plans. During the installation process, it is necessary to ensure the sealing, stability, and fire resistance of the pipeline, and avoid excessive length or curvature.

管道风机安装示意图,消防排烟风机安装图片(2) - 伤感说说吧管道风机安装示意图,消防排烟风机安装图片(2) - 伤感说说吧通风管道在建筑工程中的应用需要综合考虑设计、材料选择、尺寸设计、安装规范和防火措施等多个方面，以确保其稳定性和安全性。

Installation diagram of pipeline fan, installation picture of fire smoke exhaust fan (2) - Sad Talk Bar Installation diagram of pipeline fan, installation picture of fire smoke exhaust fan (2) - Sad Talk Bar The application of ventilation ducts in building engineering requires comprehensive consideration of design, material selection, size design, installation specifications, and fire prevention measures to ensure their stability and safety.
